Description

Product Overview

The AS-UVS Mobile Under Vehicle Security Inspection System is a portable undercarriage screening solution developed by Shenzhen Ansa Technology, engineered to deliver comprehensive vehicle inspections at any location without the need for fixed infrastructure. Combining high-resolution digital imaging with mobile deployment technology, the system captures detailed undercarriage images that reveal concealed threats, contraband, or unauthorized modifications invisible to conventional mirror inspection. Unlike fixed under-vehicle scanners, the AS-UVS brings full screening capability to remote sites, temporary events, and emergency response scenes — wherever vehicle security is needed.

Built around a 16-megapixel high-definition camera array with 360-degree panoramic imaging, the AS-UVS captures undercarriage detail at 0.1 mm resolution — enough to detect small anomalies or hidden items beneath any vehicle. The system meets ISO 27001 data security and IP68 environmental protection standards, ensuring reliable operation from urban checkpoints to remote border crossings. A rapid-deployment design allows a single operator to set up the unit in under 5 minutes, making the AS-UVS ideal for dynamic security operations that demand immediate readiness.

Product Features

Advanced Imaging Technology

• High-Resolution Camera Array— 16-megapixel color cameras with LED illumination produce detailed undercarriage images even in low-light environments.
• Panoramic Image Stitching— Built-in software automatically merges multiple camera views into a single 360-degree panoramic image with distortion correction for complete undercarriage coverage.
• AI Anomaly Detection— An optional AI module compares real-time scans against manufacturer baseline images and flags unusual modifications or foreign objects with 98.3% accuracy.

Mobile Deployment Capability

• Rapid Setup— Deployable in under 5 minutes by a single operator without specialized tools, enabling immediate security response.
• Versatile Placement— A lightweight 25 kg aluminum frame with non-slip base operates on asphalt, concrete, gravel, or dirt surfaces with no permanent installation required.
• Battery Operation— An integrated lithium-ion battery delivers 8 hours of continuous operation with quick-swap capability for extended missions.

Operational Efficiency

• High Throughput— Each vehicle is processed in 15-30 seconds, keeping traffic disruption at checkpoints to a minimum.
• Wireless Operation— Wi-Fi and Bluetooth connectivity stream live images to tablets or laptops up to 50 meters from the scanning unit.
• Day/Night Operation— Automatic low-light compensation and infrared illumination ensure clear imaging in all lighting conditions.

Data Management and Security

• Secure Image Storage— Encrypted on-board storage holds up to 10,000 inspection images with password-protected access.
• Rapid Image Retrieval— Search by date, time, license plate, or vehicle type for fast audit trail compilation.
• System Integration— Compatible with access control systems and security management software via API and standard protocols.

Applications

The AS-UVS delivers critical under-vehicle security in dynamic operational environments:

Temporary Security Operations

• Event venue vehicle screening (concerts, sports, summits)
• Construction site access control
• Emergency response checkpoints

Border and Transportation Security

• Remote border crossing inspections
• Highway checkpoint vehicle screening
• Port and harbor vehicle access control

Critical Infrastructure

• Power plant temporary security zones
• Water treatment facility perimeter control
• Pipeline construction site access

Law Enforcement

• Roadblock and checkpoint operations
• Crime scene vehicle inspection
• High-risk warrant service support

Technical Specifications

Item	Parameter
Imaging
Camera	16-megapixel high-definition color camera array
Resolution	0.1 mm
Imaging mode	360-degree panoramic stitching with distortion correction
Low-light operation	LED illumination + automatic infrared compensation
AI anomaly detection	Optional module, 98.3% accuracy
Scanning
Scanning speed	3-5 km/h (walking speed)
Inspection time	15-30 seconds per vehicle
Image processing	Within 1 second
Vehicle Compatibility
Vehicle types	Cars, SUVs, trucks, vans, commercial vehicles
Maximum wheelbase	6 m
Minimum ground clearance	12 cm
Scanner Unit
Frame material	Lightweight aluminum alloy
Weight	25 kg
Load capacity	Withstands pressure greater than 20 tons
Base	Non-slip; suitable for asphalt, concrete, gravel, dirt
Waterproof rating	IP68
Power and Connectivity
Battery	Integrated lithium-ion, 8 hours continuous operation, quick-swap
Wireless	Wi-Fi and Bluetooth, range up to 50 m
Display and Storage
Image viewing	Tablet or laptop (wireless connection)
Storage capacity	Up to 10,000 encrypted inspection images
Access control	Password-protected
Image retrieval	Search by date, time, license plate, vehicle type
Auxiliary Lighting
Light source	LED
Lifespan	Exceeds 10,000 hours
System Integration
API	Compatible with access control and security management software
Protocols	Standard industry protocols
License plate recognition	Automatic, with black/white list registration
Design
Structure	Modular design for easy maintenance
Sealing	Military-grade multi-seal protection
Setup time	Under 5 minutes, single operator, no tools required

Certifications

• ISO 14001 Environmental Management System
• ISO 9001 Quality Management System
• ISO 27001 Information Security Management
• OHSAS 18001 Occupational Health and Safety Management System
• GB/T 1336-2016 National Standard for Under Vehicle Imaging Security Inspection System
• National Ministry of Public Security Inspection Report
• EU CE Certification
• US FCC Certification
• EU RoHS Certification
• IP68 Certification
• Computer Software Copyright Registration
• Utility Model Patent
• Chinese Police Equipment Technology Innovation Award

Functional Advantages

• Fast Image Processing— Quick imaging within 1 second greatly improves work efficiency.
• Suspicious Item Detection— Auxiliary inspection functionality identifies suspicious items, improving inspection efficiency.
• Automatic Image Generation and Comparison— Enhances accuracy by automatically comparing current images with stored baseline images.
• Systematic Record Keeping— Facilitates effective queries and verification for public security and judicial departments.
• High Adaptability— Meets inspection requirements for all standard vehicle models.
• Durable Auxiliary Lighting— Imported LED lighting with a lifespan exceeding 10,000 hours.
• High-Strength Design— Military-grade safety protection technology with multiple seals.
• Modular Design— Simplified maintenance with modular components.
• High-Pressure Resistance— Withstands pressure greater than 20 tons.
• Automatic License Plate Recognition— Registers vehicles in black and white lists for automated access control.

Application Areas

Government Departments and Large Public Venues: Airports, prisons, customs, and other high-security facilities use the AS-UVS to inspect incoming and outgoing vehicles for contraband items and unauthorized modifications.

Large Events and Exhibitions: Event organizers deploy the AS-UVS at entry and exit points for rapid vehicle safety inspections during conferences, exhibitions, and sporting events.

Security, Explosive Prevention, and Military Vehicle Inspections: Military installations and explosive prevention units rely on the AS-UVS for under-vehicle security checks at access control points and temporary checkpoints.
